Footwear Impact Tester

The footwear impact tester is capable of offering the kinetic energy of 100J or 200J for the testing of steel toe cap. Users can observe the sunken conditions of the toe cap and evaluate the safety degree of the safety footwear.

The safety footwear impact testing machine employs the steel striker with the weight of 20 kg±0.2kg, which will fall freely from the preset height with energy required. The mechanism shall be set up to catch the striker after the first time impact, ensuring the test piece is struck for one time only.

Technical Parameter of Footwear Impact Tester

Model GT-KB17 GT-KB17B GT-KB17C
Drop height range 0- 1200mm
Impact energy 200±2 J 100±2 J 101.7±2 J
Impact hammer Wedge, Length 75mm, Angle 90° Cylinder, Diameter 25.4mm
Impact surface Corner radius R3 mm Spherical radius R25.4mm Length 152.4±3.2 mm
Impact hammer mass 20±0.2 kg 22.7±0.23kg
Power supply Customizable
Dimensions(L x W x H) 60 x 70 x 220cm
Weight 230kg
Standards EN ISO 20344 Section 5.4 and 5.16, AS/NZS 2210.2 Section5.4 and 5.16 GB/T 20991 Section 5.4 and 5.16, BS EN-344-1 Section 5.3 BS-953 Section 5, ISO 20345 EN 12568 Section 5.2.2 CSA-Z195-14 Section 6.2, ANSI-Z41 Section 1.4.5 , ASTM F2412 Section 5, ASTM F2413 Section 5.1, NOM-113-STPS-2009 Section 8.3 CSA-Z195-14 Section 6.4, ASTM F2412 Section 7, ASTM F2413 Section 5.3, NOM-113-STPS-2009 Section 8.6

Accessories

Standard accessories 1set Toecap clamp device
1pc Power line
Option accessories Air compressor
Metatarsal protective test clamp device for EN ISO 20344 Section 5.16
