Application
This machine is to test the resistance to discoloration of shoes materials.Such as white and light color upper materials, sole materials, leather, PU, fabric etc. To assess the defect of products the radiation from sun in normal use and high temperature of container during the transport.
This machine also can be used as the aging tester and dying oven, multi-use of one machine.
Key Specification
Model | |
Light source | OSRAM fluorescent UV lamp |
Lamp power | 300W |
Lamp Irradiance | ( 25 ( 0.4) W/m2 |
Lamp service life | 1000h |
Temp. range | RT ~ 120℃ |
Temperature resolution | 0.1℃ |
Heating method | hot-air circulation |
Timer | LED, 0 - 999 hr |
Turntable diameter | 45 cm |
Revolutions | 3 rpm |
Interior chamber | 50 x 50 x 60 cm |
Power supply | 1∮AC 220V 50/60HZ |
Dimensions(W x D x H) | 88 x 70 x 156 cm |
Weight | 140 kg |
Standards | ASTM-D1148 HG/T 3689 |
